Solar Dc Pump (DC40C)

太阳能无刷直流水泵(DC40C)
Product name:Solar Dc Pump (DC40C)
Item:
Details:
DC40C Series
Solar DC Pump,Brushless Dc Pump,Bldc Pump,Submersible dc Pump

 Dc40 series Solar DC Pump
Mode Note:
 Dc40 series Solar DC Pump Mode Note
Specifications
NO
Items
Specs
1
Sizes and weight
85.5x82x48;250g
2
Dimension of inlet
20mm(1/2 inch thread)
3
Dimension of outlet
20mm(1/2 inch thread)
4
Driving method
Brushless, Magnetic , 2 phase or 3 phase
5
Pump material
PA66+GF30% (optional)
6
Condition of use
Continuously
7
Fluids
Water, oil,
gasoline, acid and alkali solution etc
8
Max working temp
60(2 phase)or 100(3 phase)
9
Power consumption
3.25W~26.4W
10
Rated voltage
12V or 24Vdc
11
Voltage used
5Vdc ~ 12Vdc or 5Vdc ~ 24Vdc
12
Max rated current
1.2A
13
Max flow rate
18L/MIN(4.76G/MIN)
14
Max Static Head
4.5m(14.6ft)
15
Noise
 <35dB
16
Water proof class
IP68(can be submersible installed)
17
Life span
More than 30000hrs
18
Power supply
Solar panel; DC electric source; battery

Parameter
(only for reference, it can be customized)
Model
Voltage
Current
Max flow
Max head
V
A
L/H
G/H
M
ft
DC40C-1230
12
1.1
840
222
3.0
9.7
DC40C-2440
24
1.1
1080
286
4.5
14.6
Remarks
The current above is starting current, when contact to circulation system the current will cut down to 55%~65% of Rated current.

Advantages of our DC pump
Ø
1.Brushless, permanent magnetic rotor, maintenance-free, long life.

2. Small size, high efficiency, low consumption, low noise.

3.Ceramic sleeve and ceramic shaft optional.

4.and circuit board sealed by epoxy resin, completely water proof.

 5.Parameter adjustable, 12v pump’s head can be 1.5m to 3m.

6.Can be customized.

Dimension and Picture
 Dc40 series Solar DC Pump Dimension and Picture

Head-Flow curve Graph

 Dc40 series Solar DC Pump Head-Flow curve Graph
